The Smart Graders deliver accurate fish grading while minimizing the impact on your fish as they pass through the outlets. The dewatering unit distributes the fish evenly over the width of the grader, so all grading tracks are used effectively.The opening of the grader is controlled with electric linear actuators that can be operated from a control panel on the grader, remotely from a smart device or automatically from the VAKI Counter which counts, size measures and calculates the split between the grades.The size opening for each grade is displayed on the digital display. The grader is built in high grade stainless steel 316L and selected plastic materials that are corrosion and water resistant. The inclination of the main sorting unit can be adjusted from 5-10° either with an electric actuator or manually.
Features
- Full width fish inlet for maximum spread of fish.
- Live fish grading with 60mm diameter rollers.
- Electronic adjustment of grade size settings and grader tilt.
- High precision grading.
- Connection to VAKI Smart Flow.
- Connection to VAKI Cloud
Operation and Adjustment:
-
- Outlets can be mounted to deliver the fish on either side of the grader and are easily disassembled for cleaning.
- Operate the grader opening via a control panel , remotely from a smart device or automatically via the VAKI Counter, which counts, measures size and calculates the split between grades.
- Electric linear actuators control opening.
- Digital display shows the size opening for each grade.
- Change the main sorting unit inclination from 5-10°.
The rollers are machined in with high precision laser welding tools and balanced out with specialized equipment. It delivers an accurate grading of the fish. The outlets are designed to minimize the impact on the fish and can be mounted to deliver the fish on either side of the grader. These outlets can easily be removed for cleaning. The rotation speed of the rollers can be adjusted with a frequency controller.
Specification
Macro Smart Grader
- 10 tracks
- Grades fish 5-55mm thick
- Live fish grading with 60mm diameter rollers
- Recommended size range:5-500g (Salmon)
- Electronic grader tilt
- Capacity: 2000-8000kg/h (Salmon)
- Dimensions: 3100mm x 1800mm x 1700mm (LxBxW)
- Outlets: D=152mm
Micro Smart Grader
- 5 tracks
- Grades fish 5-55mm thick
- Live fish grading with 60mm diameter rollers
- Recommended size range:5-500g (Salmon)
- Manual grader tilt
- Capacity: 1000-4000 kg/h (Salmon)
- Dimensions: 3000mm x 1200mm x 1300mm (LxBxW)
- Outlets: D=152mm
Exel Smart Grader
- 7 Tracks
- Live fish grading with 80mm diameter rollers
- Recommended size range: up to 2kg (Salmon)
- Electronic grader tilt
