Senect ORP Controller

Q: Is the ORP probe included?

Yes — unlike the wider SENECT range, this controller ships with the ORP sensor and the actuator cable, so there is no separate probe to order.

Q: What ORP range and accuracy does it read?

-1,000 mV to +1,000 mV at ±2.5% accuracy, on a 6 m cable as standard. Senect does not publish a resolution figure for this sensor.

Q: How does it control the ozone generator?

It sends a 4-20 mA signal to the generator and modulates injection to hold your set ORP level, for example 300 mV.

Q: Will it work with my ozone generator?

It will if the generator accepts a 4-20 mA control input. It is commonly paired with ClearWater Tech generators and we can wire the complete package before shipping.

Q: What are the spare relays for?

Two of the three relays are free once ozone control is assigned, so you can also switch a feeder, lighting, a pump or an alarm from the same unit.

Q: What if I need to control more than ORP?

Step up to the wider SENECT range, which offers up to 6 sensor inputs and 6 relays and covers dissolved oxygen, pH and conductivity as well.

Q: Can I change the set point remotely?

Yes — over WiFi through the free SENECT Control App on a phone, tablet or PC, which also pushes alarm messages.

A controller that holds a set ORP level by adjusting the ozone generator, for ozone dosing in RAS and water treatment.

$2,800.00 ex GST

SKU: SEN-ORP

Categories: Monitoring Systems, Oxygen & Ozone, Water Quality Monitoring

Applications: Live Holding & Purging, LSS, Pond, RAS, Water & Wastewater Treatment

Brand: Senect

Product Information

Key Features

Closed-loop ozone control — the unit holds a set ORP level (300 mV, for example) instead of dosing blind, which removes the overdose risk
ORP sensor and actuator cable are supplied with the controller, so it works out of the box; no probe to order separately
Sensor measures -1,000 mV to +1,000 mV with ±2.5% accuracy, on a 6 m cable as standard with extensions available
Replaceable electrode with a BNC connector in a silicone-housed transducer, so a worn probe is a cheap consumable rather than a new controller
Drives the ozone generator over a 4-20 mA signal, with 3 output relays in total — one for ozone, two spare for a feeder, lights or a pump
Built-in WiFi (WLAN) and the free SENECT Control App for remote monitoring, set point changes and push alarms from phone, tablet or PC
Scalable — several Senect units combine into a single software system, and we can wire a complete ozone package before shipping for plug-and-play start-up
This is a single-parameter, single-loop controller with one sensor input, so there is no model to size: check your ORP set point sits inside the -1,000 to +1,000 mV range, that your ozone generator accepts a 4-20 mA input, and that two spare relays are enough for anything else you want switched. If you need more parameters or more relays, move up to the wider SENECT range.

Specifications

Specification	Detail
Measured parameter	ORP (redox potential), mV
ORP measuring range	-1,000 mV to +1,000 mV
ORP accuracy	±2.5%
ORP resolution	Contact us
Sensor supplied	Yes — ORP sensor and actuator cable included with the controller
Sensor cable	6 m standard; extensions available
Electrode	Replaceable, BNC connector; transducer in silicone housing
Measurement principle	Electrochemical
Sensor inputs	1
Control output to ozone generator	4-20 mA actuator signal
Output relays	3 total — 1 for ozone control, 2 spare for feeder, lighting or similar
Control method	Maintains a user-set ORP level, modulating ozone injection to hold it
Connectivity	Built-in WiFi (WLAN); free SENECT Control App on smartphone, tablet, PC and Apple
Network support	WEP and WPA / WPA2 Personal; WPA Enterprise is not supported
Multi-unit operation	Several Senect units combine into one software system
Product code	SEN-ORP
Power supply	Contact us
Typical duty	Ozone dosing control in RAS, ponds, raceways, intake water and wastewater treatment

Downloads

Senect One Spec Sheet ORP Sensor Spec Sheet

Frequently Asked Questions

Is the ORP probe included?

What ORP range and accuracy does it read?

How does it control the ozone generator?

Will it work with my ozone generator?

What are the spare relays for?

What if I need to control more than ORP?

Can I change the set point remotely?
