OXYMAT publishes 65 dB at 2.7 bar(g) outlet pressure.

OXYMAT O200 Series Oxygen Generators (up to 84m3/hr)

Q: What purity and pressure does the O200 Series deliver?

Outlet pressure is adjustable from 2.5 to 6.0 bar(g) at purities up to 95%; the stocked models are rated at 93% O₂ and 4 bar(g).

Q: Which O200 model do I need?

Match your peak demand at 93% O₂ and 4 bar(g) — O200-1 gives 26.8 kg/hr, O200-2 gives 53.6 kg/hr, O200-3 gives 75 kg/hr and O200-4 gives 93.8 kg/hr.

Q: What makes the O200 different from the Pallet Series?

It is a low-pressure PSA machine, so it will run down to 2.5 bar(g) outlet where power drops to around 0.7 kWh per Nm³, against 0.8 kWh per Nm³ for the Pallet range.

Q: What does the oxygen cost to produce?

About $0.15 per m³ or $0.11 per kg on an O200-4 at 93% purity and 2.5 bar(g), based on $0.20/kWh.

Q: Can it be integrated with our control system?

Yes — Modbus RTU and a 7” touch screen are standard, with a 4.3” screen on the smaller capacities.

Q: How do I get a price?

Request a quote with your peak oxygen demand in kg/hr, your required outlet pressure and whether you need air preparation — we’ll come back with the right model, configuration and lead time.

On-site oxygen generators for supplying large aquaculture farms and processing plants with oxygen.

Model

Clear

Request a Quote

Categories: Oxygen & Ozone

Applications: Hatchery, Live Holding & Purging, LSS, Public Aquarium, RAS

Brand: OXYMAT

OXYMAT O200 Series Oxygen Generators (up to 84m3/hr)

OXYMAT O200 Series Oxygen Generators (up to 84m3/hr) - Image 2

Product Information

Key Features

Four stocked sizes — O200-1 to O200-4 — delivering 357, 714, 1,000 and 1,250 LPM of oxygen (20.1, 40.2, 56.28 and 70.35 Nm³/hr) at 93% O₂ and 4 bar(g) outlet
Low-pressure PSA (LPSA) design — OXYMAT rates power consumption from 0.7 kWh per Nm³ of oxygen and claims a 40% reduction against conventional PSA generators
Outlet pressure adjustable from 2.5 to 6.0 bar(g), at purities up to 95%; at the 2.5 bar(g) LPSA duty an O200-4 makes 63.32 Nm³/hr for 47.57 kW, about $0.15 per m³ at $0.20/kWh
Quiet for its size at 65 dB measured at 2.7 bar(g) outlet pressure
7” touch screen with advanced control (4.3” on the smaller capacities), Modbus RTU and LED visual operation status
All pipe sets and valves in SS 316L stainless; pressure vessels sandblasted and powder coated P265 to C4 grade for extended life
Built in Denmark and supplied with Australian and New Zealand certification; modular, so capacity can be added as demand grows
Sizing: work out your peak oxygen demand in kg/hr, then pick the model that covers it at 93% O₂ and 4 bar(g) — O200-1 to 26.8 kg/hr, O200-2 to 53.6 kg/hr, O200-3 to 75 kg/hr, O200-4 to 93.8 kg/hr. Below 20 Nm³/hr look at the Pallet Series. Tell us your required outlet pressure too, because the O200 gains output when run at the lower 2.5 bar(g) LPSA duty.

Specifications

Model	Code	Oxygen output @ 93% O₂, 4 bar(g)	Output by mass @ 93% O₂	Power consumption
O200-1	O200-1	357 LPM (20.1 Nm³/hr)	26.8 kg/hr	Not published by supplier
O200-2	O200-2	714 LPM (40.2 Nm³/hr)	53.6 kg/hr	Not published by supplier
O200-3	O200-3	1,000 LPM (56.28 Nm³/hr)	75 kg/hr	Not published by supplier
O200-4	O200-4	1,250 LPM (70.35 Nm³/hr)	93.8 kg/hr	Not published by supplier at this duty
O200-4 at LPSA duty	O200-4	63.32 Nm³/hr @ 93% O₂, 2.5 bar(g)	84.4 kg/hr	47.57 kW
All models	—	Outlet pressure adjustable 2.5 to 6.0 bar(g), purity up to 95%	Energy from 0.7 kWh/Nm³	65 dB @ 2.7 bar(g); Modbus RTU; SS 316L pipework; built in Denmark

Downloads

OXYMAT O200-4 Nordic Line Datasheet

Frequently Asked Questions

What purity and pressure does the O200 Series deliver?

Which O200 model do I need?

What makes the O200 different from the Pallet Series?

What does the oxygen cost to produce?

How loud is it?

Can it be integrated with our control system?

How do I get a price?
