Waterco Supastream Pumps (up to 400LPM)

Work out your required flow and your total head, including pipe friction and any filter or UV losses, then pick the model that meets that flow at that head – a flow figure without a head figure does not size a pump.

That is the pump curve: the Supastream 100 gives 330 LPM at 2 m head, 234 LPM at 8 m and 169 LPM at 10 m, so the duty point decides the model, not the headline flow.

Waterco does not publish a suction lift figure for the Supastream, so we size it on flooded suction by default – tell us your suction arrangement and we will confirm it.

All four Supastream models are single phase, 220-240 V; for three phase, step up to the Hydrostar Plus range.

Yes, with the optional sea water mechanical seal (SKU Supastream-SW); the standard 316 stainless seal already resists chlorinated water, ozone, iodine, bromine and Baquacil.

It sits between the wet end and the motor and drains any leak from a worn mechanical seal away from the motor end shield, which is what usually destroys a pool-style pump.

It is the low-pressure, general-purpose entry point; Hydrostorm and TurboFlo carry more head, and Hydrostar Plus covers the large duties up to 2,600 LPM at 10 m head.
