Ecotech Vectra Pumps – S2, M2 and L2

Q: How do I choose the right pump?

Work out your required flow and your total head, including pipe friction and any filter or UV losses, then pick the model that meets that flow at that head — the figures here are maximum flow at full speed, so allow headroom and ask us for the curve if your duty point is tight.

Q: Are Vectra pumps suitable for salt water?

Yes — they are built for marine reef aquariums and commercial aquaculture systems, and are supplied with seawater connections.

Q: What can I control from the app?

Mobius and ReefLink give wireless speed setting, alerts and flow programming from iOS and Android, with Constant Speed, Feed Mode and Speed Lock modes for return pump duty.

Q: Can the pump run outside the sump?

Yes — every model runs submersible or inline, as a return pump or a closed-loop flow pump, and the volute rotates so you can align the outlet without adapters.

Q: What happens in a power outage?

The Vectra range is battery backup compatible, so water keeps moving through a blackout; the battery backup is a separate accessory.

Q: How much power does a Vectra draw?

Power draw is not stated in the literature we hold for this page — contact us and we will confirm the figure for the model you are considering.

Q: Which model suits my system?

Match your turnover rate and total head to the model that still delivers it: S2 up to 5,300 L/hr, M2 up to 7,500 L/hr and L2 up to 11,500 L/hr.

Controllable DC pumps for return and circulation duty in marine and freshwater aquariums.

Price range: $580.00 through $980.00 ex GST

Models

Clear

Categories: Submersible Pumps, Water Pumps

Applications: LSS, Public Aquarium, Reef Aquarium

Brand: EcoTech

Ecotech Vectra Pumps - S2, M2 and L2 - Image 2

Ecotech Vectra Pumps - S2, M2 and L2 - Image 3

Ecotech Vectra Pumps - S2, M2 and L2 - Image 4

Ecotech Vectra Pumps - S2, M2 and L2 - Image 5

Ecotech Vectra Pumps - S2, M2 and L2 - Image 6

Product Information

Key Features

Three controllable DC pumps — S2, M2 and L2 — with maximum flows of 5,300, 7,500 and 11,500 L/hr
QuietDrive DC motor technology for lower noise and vibration than a conventional AC pump, and lower running cost
Mobius and ReefLink wireless control from iOS and Android for real-time speed setting, alerts and flow programming
Constant Speed, Feed Mode and Speed Lock modes for return pump duty
Runs submersible or inline, as a return pump or a closed-loop flow pump
Rotating volute and QuickCouple fittings align the flow and speed up installation and servicing
Battery backup compatible (accessory sold separately) to keep water moving through a power outage
To size a pump, work out your required flow and your total head, including pipe friction and any filter or UV losses, then pick the model that meets that flow at that head

Specifications

Model	SKU	Maximum flow	Inlet	Outlet	Control
Vectra S2	Vectra S2 Pump	5,300 L/hr	20 mm	32 mm	Variable speed DC, Mobius wireless
Vectra M2	Vectra M2 Pump	7,500 L/hr	32 mm	25 mm	Variable speed DC, Mobius wireless
Vectra L2	Vectra L2 Pump	11,500 L/hr	40 mm	32 mm	Variable speed DC, Mobius wireless

Downloads

Vectra Pump Range Spec Sheet Vectra Pump Setup Guide

Frequently Asked Questions

How do I choose the right pump?

Are Vectra pumps suitable for salt water?

What can I control from the app?

Can the pump run outside the sump?

What happens in a power outage?

How much power does a Vectra draw?

Which model suits my system?

Spare Parts & Consumables

No products were found matching your selection.

Ecotech Vectra Pumps – S2, M2 and L2

Product Information

Key Features

Specifications

Downloads

Frequently Asked Questions

Spare Parts & Consumables
