Both are standard — the RAS1000 is built either as a single 1,000 L tank or as 2 x 500 L tanks on shared filtration, which suits replicated trials and teaching groups.

RAS1000 – Recirculating Aquaculture Systems 1000L

Q: What does the 1000 in RAS1000 refer to?

It is the nominal system water volume in litres. FBD does not publish whether that figure is total or working volume, so confirm it with us at design stage.

Q: How much fish will a RAS1000 hold?

FBD does not publish a biomass or stocking density for these systems, because capacity depends entirely on species and water temperature — we size it against your species at quotation.

Q: What is included as standard?

Tanks, FBD filter sump with 3 x 100 µm bag filters, MBBR with C1 bio media and air diffusers, UV steriliser, recirculation pump, aeration with backup power, heater/chiller, carbon intake cartridge filter and a water quality test kit.

Q: What do I need to supply on site?

A level footprint, mains power and a water supply — send us your available space and power and the system is designed to suit.

Q: Should I take the RAS2000 instead?

Step up to the RAS2000 if you need 2,000 L of system volume or want up to four separate tanks; the RAS5000 is the largest in the range at 5,000 L.

Q: How do I get a price?

Request a quote with your species, design biomass, water temperature, fresh or salt water, site footprint and available power, and we’ll come back with a system design, price and lead time.

A complete 1,000 L recirculating aquaculture system for teaching, research and small-scale production.

Categories: Aquaculture Systems

Applications: Aquaponics, RAS

RAS1000 - Recirculating Aquaculture Systems 1000L

RAS1000 - Recirculating Aquaculture Systems 1000L - Image 2

RAS1000 - Recirculating Aquaculture Systems 1000L - Image 3

RAS1000 - Recirculating Aquaculture Systems 1000L - Image 4

RAS1000 - Recirculating Aquaculture Systems 1000L - Image 5

RAS1000 - Recirculating Aquaculture Systems 1000L - Image 6

Product Information

Key Features

1,000 L nominal system water volume — the number in the model name is the system water volume in litres; FBD does not publish whether that is total or working volume
Supplied as a single 1,000 L aquaculture tank or as 2 x 500 L tanks, so the same water volume can be split into two independent rearing units
Second of four sizes in the FBD RAS range — RAS500, RAS1000, RAS2000 and RAS5000 — step up to the RAS2000 if you need more water volume or up to four tanks
FBD filter sump carries 3 x 100 µm bag filters plus MBBR with C1 bio media and built-in air diffusers, followed by UV steriliser and recirculation pump
Aeration with backup power supply, heater/chiller temperature control, carbon cartridge filter for intake water and a water quality test kit are all included as standard
Built for fresh water or salt water, specified at design stage
Options include tank lid and viewing window, filter sump lid, automated monitoring, automatic feeders, and grow beds or a vertical green wall
To size and quote, send FBD your species, design biomass, water temperature, fresh or salt water, water source, available site footprint and power supply

Specifications

Specification	RAS500	RAS1000	RAS2000	RAS5000
Model on this page	-	This system	-	-
Nominal system water volume	500 L	1,000 L	2,000 L	5,000 L
Stated as total or working volume	Not published	Not published	Not published	Not published
Tank configuration	500 L aquaculture tank	1,000 L tank or 2 x 500 L tanks	2,000 L tank, 2 x 1,000 L or 4 x 500 L tanks	2 x 2,000 L tanks
Mechanical filtration (FBD filter sump)	100 µm bag filters, quantity not published	3 x 100 µm bag filters	3 x 100 µm bag filters	100 µm bag filters, quantity not published
Biological filtration - MBBR with C1 bio media and built-in air diffusers	Included	Included	Included	Included
Disinfection - UV steriliser	Included	Included	Included	Included
Recirculation pump	Included, duty not published	Included, duty not published	Included, duty not published	Included, duty not published
Aeration with backup power, heater/chiller, carbon intake cartridge filter, 1 x water quality test kit	Included	Included	Included	Included
Fresh water or salt water build	Specified at design	Specified at design	Specified at design	Specified at design
Design biomass or stocking density	Not published	Not published - sized against your species and water temperature	Not published	Not published
Turnover rate	Not published	Not published	Not published	Not published
Power supply	Not published	Not published	Not published	Not published
Footprint and dimensions	Not published	Not published	Not published	Not published
Optional - tank lid and viewing window, filter sump lid, automated monitoring, automatic feeders, grow beds or vertical green wall	Available	Available	Available	Available
To size and quote, FBD needs - species, design biomass, water temperature, fresh or salt water, water source, site footprint, available power	Send with enquiry	Send with enquiry	Send with enquiry	Send with enquiry

Frequently Asked Questions

What does the 1000 in RAS1000 refer to?

One tank or two?

How much fish will a RAS1000 hold?

What is included as standard?

What do I need to supply on site?

Should I take the RAS2000 instead?

How do I get a price?
