The D116 Series Ultrasonic flowmeter is a state of the art flowmeter that uses broadband pulse transmission to measure flow rates.
Comparing with other traditional flowmeters, this unit has distinctive features such as:
- High reliability
- High precision
- High capability
- Low cost
- Low power consumption
- User friendly
- Simple user interface
It also gives users the ability to conveniently get simple daily, weekly, monthly and yearly totalised water consumption.
| Performance specifications | |
| Flow range | ‡0.01m/s~ ‡5m/s |
| Accuracy | ‡0.5m/s~‡5m/s |
| Pipe size | Clamp-on:1’~48″(25mm~1200mm) |
| Fluid | Water. |
| Pipe material | Carbon steel,stainless steel, PVC. |
| Function specifications | |
| Outputs | OCT Pulse output:0~5000Hz. Analog output:4~20mA, max load 7500. |
| Communication interface | RS485 MODBUS |
| Power supply | 10~36VDC/1A |
| Keypad | 16(4X4)key with tactile action |
| Display | 20X2 lattice alphanumeric, back lit LCD. |
| Temperature | Transmitter:-10°C~50°C Transducer: 0°C~80°C |
| Humidity | Up to 99% RH,non-condensing |
| Phsical specifications | |
| Transmitter | PC/ABS,IP65. |
| Transducer | Encapsulated design, IP68. |
| Transducer cable | Standard cable length:30ft(9m). |
| Weight | Transmitter:approximately 0.7kg; Transmitter:approximately 0.4 kg |
